Aluminium Stalk Lug 185mm2 14mm Shear Bolt Cabac
Cabac aluminium stalk cable lug, 185mm2, 14mm stalk diameter, shear-head bolts, jointing compound filled. Ideal for aluminium conductor joints.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Nominal Conductor Size: 185 mm²
- Cable Stalk Diameter: 14 mm
- Strand Metric I.D.: 37/2.52
- Number of Shear Head Bolts: 2
- Suitable for stranded sector and circular stranded aluminium conductors
- Supplied filled with jointing compound and capped
- Dimensions (H x L x W): 24 mm x 185 mm x 24 mm
- Weight: 0.2 kg
Key Features
- Suitable for stranded sector and circular stranded aluminium conductors
- Supplied filled with jointing compound and capped
- Crimped with standard aluminium hex dies
- Includes 2 shear head bolts for secure attachment
Professional Installation Requirements
- Installation should be performed by a qualified electrician using standard aluminium hex crimping dies for secure and compliant connections.
Applications
- Electrical connections for aluminium overhead conductors
- Attachment of aluminium cables to aluminium clamp terminals
- Use in electrical equipment requiring aluminium lugs
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Aluminium material is lightweight and recyclable, reducing environmental impact
- Durable design extends product life and reduces waste
Warranty Information
Warranty details available upon request from manufacturer.
Available Now
The Cabac AL Stalk 185mm2 Cable 14mm Stalk is available for immediate purchase, ideal for electrical and power connectivity applications involving aluminium conductors.
