Ammeter Dial 1.5In for TC100/5 | 0-100A Scale | Analog Display | by Clipsal
The Ammeter Dial 1.5In for TC100/5 is designed for precise current monitoring with a scale range of 0 to 100 Amps. This analog display features a clear 1.5-inch diameter for easy visibility, making it ideal for electrical switchboards and industrial control panels. Built with durable materials, it ensures long-term reliability and compliance with safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ammeter Dial 1.5In for TC100/5 | 0-100A Scale | Analog Display | by Clipsal
Brand: Clipsal
SKU: SCH16010
Alternatively Known As: Ammeter scale for TC100/5, Clipsal analog ammeter dial, 1.5 inch ammeter faceplate, SCH16010 ammeter dial, 0-100A ammeter dial
Technical Specifications
- Compatible with TC100/5 current transformer
- Scale range: 0 to 100 Amps
- Analog display
- 1.5 inch (38mm) dial diameter
- Material: High-quality plastic and printed scale
- Mounting: Panel mount
- Dimensions (H x L x W): 38mm x 10mm x 38mm
- Weight: 0.12 kg
Key Features
- Analog ammeter dial for TC100/5 current transformer
- 1.5 inch diameter for clear visibility
- Scale range: 0 to 100 Amps
- Easy-to-read graduated markings
- Durable construction for long-term use
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure correct integration with current transformers and electrical panels.
Applications
- Electrical switchboards
- Industrial control panels
- Power distribution units
- Generator monitoring
- Commercial and industrial electrical installations
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables accurate current monitoring to help optimize energy usage and reduce waste
- Durable design minimizes replacement frequency, reducing material waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Ammeter Dial 1.5In For TC100/5 (SCH16010) is available for immediate purchase. Ideal for electrical switchboards, control panels, and industrial monitoring applications.
