Analog Position Sensor MPS-128TSTP0 | 128 mm Measuring Range | IP67 Rated | Analog Output 0-10V or 4-20mA | by SICK
The Analog Position Sensor MPS-128TSTP0 is designed for precise position sensing in industrial automation, featuring a 128 mm measuring range and IP67 rated enclosure for dust and water protection. With versatile analog output options of 0-10V voltage or 4-20mA current, it's perfect for applications in pneumatic and hydraulic cylinders, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Analog Position Sensor MPS-128TSTP0 | 128 mm Measuring Range | IP67 Rated | Analog Output 0-10V or 4-20mA | by SICK
Brand: SICK
SKU: 1045672
Alternatively Known As: Analog Position Sensor, T-slot Cylinder Sensor, SICK MPS Sensor, Linear Position Transducer
Technical Specifications
- Measuring range: 128 mm
- Housing length: 141 mm
- Output function: Analog voltage 0-10 V or current 4-20 mA
- Electrical wiring: DC 4-wire
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 22 mA without load
- Max load resistance: ≤ 500 Ω at 24 V
- Min load resistance: ≥ 2 kΩ
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection: Yes
- Status indicator LED: Yes
- Teach-in function: Yes
- Operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- EMC compliance: EN 60947-5-7
- Connection: Cable with M8 male connector, 4-pin, 0.3 m
- Cable diameter: 2.6 mm
- Cable material: PUR
- Housing material: Plastic
- Dimensions (H x L x W): 20mm x 141mm x 20mm
- Weight: 0.3 kg
Key Features
- T-slot cylinder type compatible with round body, profile, tie-rod, dovetail groove, and SMC rail cylinders
- Measuring range of 128 mm
- Analog output options: 0 V to 10 V voltage or 4 mA to 20 mA current
- IP67 rated enclosure for dust and water protection
- DC 4-wire electrical wiring
- Teach-in control panel for easy adjustment and resetting measuring range
- Reverse polarity and short-circuit protection
- Status indicator LED for operational feedback
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and calibration.
Applications
- Industrial automation for position sensing
- Measurement in pneumatic and hydraulic cylinders
- Factory and process automation requiring precise analog output
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements, minimizing waste
- Low power consumption of 22 mA supports energy-efficient operation
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-128TSTP0 Analog Position Sensor is available for immediate purchase, ideal for industrial automation and precise position measurement applications.
