Analog Position Sensor MPS-160TSNP0 | T-Slot Cylinder Type | IP67 Rated | 160 mm Measuring Range | by SICK
The Analog Position Sensor MPS-160TSNP0 is designed for precise position sensing in industrial automation, featuring a T-slot cylinder type and a measuring range of 160 mm. With an IP67 rating for dust and water protection, this sensor is perfect for applications in pneumatic and hydraulic cylinders, ensuring reliable performance even in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Analog Position Sensor MPS-160TSNP0 | T-Slot Cylinder Type | IP67 Rated | 160 mm Measuring Range | by SICK
Brand: SICK
SKU: 1053839
Alternatively Known As: Analog Position Sensor, Linear Position Sensor, T-slot Cylinder Sensor, SICK MPS Sensor
Technical Specifications
- Cylinder type: T-slot
- Measuring range: 160 mm
- Output function: Analog (0 V ... 10 V or 4 mA ... 20 mA)
- Electrical wiring: DC 4-wire
- Enclosure rating: IP67
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 22 mA without load
- Max load resistance: ≤ 500 Ω at 24 V
- Min load resistance: ≥ 2 kΩ
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection: Yes
- Status indicator LED: Yes
- Operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- Connection type: Cable with M8 male connector, 4-pin, 0.3 m
- Cable specifications: PUR, 0.08 mm² conductor cross section, 2.6 mm diameter
- Dimensions (H x L x W): 20mm x 173mm x 20mm
- Weight: 0.2 kg
Key Features
- T-slot cylinder type compatible with various cylinder profiles
- Measuring range of 160 mm
- Analog output options: 0 V to 10 V voltage or 4 mA to 20 mA current
- Electrical wiring: DC 4-wire
- Enclosure rating IP67 for dust and water protection
- Supply voltage range from 15 V DC to 30 V DC
- Low power consumption of 22 mA without load
- Reverse polarity and short-circuit protection
- Status indicator LED for operational feedback
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
- Cable with M8 male connector, 4-pin, 0.3 m length
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for position sensing
- Measurement in pneumatic and hydraulic cylinders
- Factory and process automation requiring precise linear position feedback
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable IP67 rated housing reduces replacement frequency and waste
- Low power consumption contributes to energy efficiency in automation systems
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-160TSNP0 Analog Position Sensor is available for immediate purchase, ideal for industrial automation and precise position measurement applications.
