Analog Position Sensor MPS-160TSNU0 | T-Slot Cylinder Type | 160 mm Measuring Range | IP67 Rated | by SICK
The Analog Position Sensor MPS-160TSNU0 is designed for precise position sensing in industrial automation, featuring a 160 mm measuring range and T-slot cylinder compatibility. With analog output options of 0 V to 10 V or 4 mA to 20 mA, it ensures reliable performance in pneumatic and hydraulic applications. Built to withstand harsh environments, this sensor is IP67 rated, making it ideal for factory and process automation requiring accurate linear feedback.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Analog Position Sensor MPS-160TSNU0 | T-Slot Cylinder Type | 160 mm Measuring Range | IP67 Rated | by SICK
Brand: SICK
SKU: 1050922
Alternatively Known As: Analog Position Sensor, Linear Position Sensor, T-slot Cylinder Sensor, SICK MPS Sensor
Technical Specifications
- Cylinder type: T-slot
- Measuring range: 160 mm
- Output function: Analog voltage 0 V to 10 V or current 4 mA to 20 mA
- Electrical wiring: DC 4-wire
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 22 mA without load
- Max load resistance: ≤ 500 Ω at 24 V
- Min load resistance: ≥ 2 kΩ
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection: Yes
- Status indicator LED: Yes
- Operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- EMC compliance: EN 60947-5-7
- Connection type: 4-wire cable, 2 m length, PUR jacket
- Cable diameter: 2.6 mm
- Bending radius: Fixed installation > 5x cable diameter, flexible use > 10x cable diameter
- Housing material: Plastic
- Dimensions (H x L x W): 20mm x 173mm x 20mm
- Weight: 0.3 kg
Key Features
- T-slot cylinder type compatible with various cylinder profiles
- Measuring range of 160 mm
- Analog output options: 0 V to 10 V voltage or 4 mA to 20 mA current
- IP67 rated enclosure for dust and water protection
- Supply voltage range from 15 V DC to 30 V DC
- Reverse polarity and short-circuit protection
- Status indicator LED for operational feedback
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and compliance with electrical safety standards.
Applications
- Industrial automation for position sensing
- Measurement in pneumatic and hydraulic cylinders
- Factory and process automation requiring precise linear position feedback
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements, minimizing waste
- Low power consumption of 22 mA reduces energy usage in automation systems
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK MPS-160TSNU0 Analog Position Sensor is available for immediate purchase, ideal for industrial automation and precise position measurement applications.
