Analog Position Sensor MPS-192TSTU0 | 192 mm Measuring Range | IP67 Rated | Analog Output Options | by SICK
The Analog Position Sensor MPS-192TSTU0 is designed for precise position measurement in industrial automation. With a measuring range of 192 mm and IP67 rated for dust and water protection, it’s perfect for harsh environments. Featuring analog output options of 0 V to 10 V or 4 mA to 20 mA, this sensor ensures reliable performance and easy integration with various cylinder types.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Analog Position Sensor MPS-192TSTU0 | 192 mm Measuring Range | IP67 Rated | Analog Output Options | by SICK
Brand: SICK
SKU: 1050738
Alternatively Known As: Analog Position Sensor, T-slot Cylinder Sensor, SICK MPS Sensor, Industrial Position Transducer
Technical Specifications
- Dimensions (H x L x W): 20mm x 205mm x 30mm
- Weight: 0.3 kg
Key Features
- T-slot cylinder type compatible with various cylinder adapters
- Measuring range of 192 mm
- Analog output options: 0 V to 10 V or 4 mA to 20 mA
- IP67 rated enclosure for dust and water protection
- DC 4-wire electrical wiring with reverse polarity and short-circuit protection
- Resolution of 0.03% FSR and repeat accuracy of 0.06% FSR
- Operating temperature range from -20°C to +70°C
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Status indicator LED and teach-in functionality for easy adjustment
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper wiring and configuration.
Applications
- Industrial automation for precise position measurement
- Use with round body, profile, tie-rod, dovetail groove cylinders
- Suitable for harsh environments requiring IP67 protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable plastic housing and PUR cable increase product lifespan reducing waste
- Low power consumption of 22 mA without load
- High reliability with MTTFD of 215 years and mission time of 20 years
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for details.
Available Now
The SICK MPS-192TSTU0 Analog Position Sensor is available for immediate purchase, ideal for industrial automation and precise position measurement applications.
