Arteor™ 2-Way Double Pole Switch | 20 AX Rated | Round Design | Matt Lacquered Magnesium | @EA of 1 | by Legrand
The Arteor™ 2-way double pole switch is designed for safe disconnection with a 20 AX rating, making it ideal for residential and commercial electrical wiring. Featuring a round design with 2 modules and a durable matt lacquered magnesium finish, this switch ensures reliable performance and environmental safety with halogen-free materials. Perfect for modular installations, it combines functionality with modern aesthetics.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Arteor™ 2-Way Double Pole Switch | 20 AX Rated | Round Design | Matt Lacquered Magnesium | @EA of 1 | by Legrand
Brand: Legrand
SKU: 573177
Alternatively Known As: Double Pole Light Switch, 2-Way Switch, 20 Amp Switch, Modular Electrical Switch, Legrand Arteor Switch
Technical Specifications
- Rated current: 20 A
- Rated voltage: 250 V AC
- Switch type: Double pole, 2-way
- Number of modules: 2
- Material: Thermoplastic, halogen free
- Surface finish: Matt lacquered magnesium
- Degree of protection: IP40
- Impact resistance: IK04
- Connection type: Screwed terminal
- Operating temperature range: -5 to 50 °C
- Storage temperature range: -10 to 70 °C
- Frequency: 50-60 Hz
- Cable section compatibility: 6-6 mm²
- Dimensions (H x L x W): 45mm x 42.2mm x 45mm
- Weight: 0.1 kg
Key Features
- 20 AX rated double pole switch for safe disconnection
- Round design with 2 modules for modular installation
- Made from thermoplastic material with a matt lacquered magnesium finish
- IP40 rated for protection against solid objects
- IK04 impact resistance for durability
- Screwed terminal connection for secure wiring
- Halogen free material for environmental safety
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper wiring.
Applications
- Residential electrical wiring for lighting and power control
- Commercial building electrical installations
- Suitable for use in domestic and light industrial environments
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen free materials reduce environmental impact
- Durable construction extends product lifespan, reducing waste
Warranty Information
Legrand offers a standard warranty covering manufacturing defects. Please refer to Legrand's official warranty policy for detailed terms.
Available Now
The Legrand Arteor 2-Way Double Pole Switch is available for immediate purchase, ideal for residential and commercial electrical wiring applications.
