ASSYplus 4 TH Glass Strip Screw | Hardened Burnished Steel | Partial Thread & RW10 Drive | @Pack of 500 | by Wurth
The ASSYplus 4 TH glass strip screw is designed for precision fastening in furniture assembly and interior construction. Made from hardened burnished steel, it features a partial thread and RW10 drive for optimal power transmission. Ideal for delicate applications, this screw ensures gap-free fastening close to edges, making it perfect for cabinet making and exhibition stand construction.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: ASSYplus 4 TH Glass Strip Screw | Hardened Burnished Steel | Partial Thread & RW10 Drive | @Pack of 500 | by Wurth
Brand: Wurth
SKU: 17883330
Alternatively Known As: Glass strip screw, partial thread wood screw, top head screw, furniture screw, RW10 drive screw
Technical Specifications
- Nominal diameter: 3 mm
- Length: 30 mm
- Thread length: 14 mm
- Screw-thread length with drill tip: 17.5 mm
- Head type: Top head 60 degree with milling ribs
- Head diameter: 5.2 mm
- Head height: 3.3 mm
- Internal drive: RW10
- Thread type: Wood screw thread
- Thread design: Partial thread
- Design: With shaft
- Thread form: Single start thread
- Core diameter: 2.1 mm
- Tip shape: Drilling tip
- Material: Hardened steel
- Surface finish: Burnished
- Max screw-in angle: 90 degrees
- Min screw-in angle: 0 degrees
- Suitable materials: Board ply wood, wood, derived timber products, hardwood, LVL, softwood
- Product weight per item: 1.127 g
- Dimensions (H x L x W): 3.3mm x 30mm x 5.2mm
- Weight: 0.0011 kg
Key Features
- Special partial thread screw with small top head and milling ribs
- Suitable for gap-free fastening close to edges of delicate glass strips or skirting boards
- Ideal power transmission with RW10 drive
- Larger contact area at the bit for more power
- Tight-fit recess for precise positioning and stability
- Compatibility with previous AW drive
- Advanced centring drill tip for precise positioning and clean drilling without chipping
- Drilling cutting edges similar to Forstner bits for maximum drilling performance
- Centring pin prevents slipping on hard surfaces
- Gentle thread start for quick screwing
- Lens-shaped rounded small screw head for unobtrusive mounting
- Milling ribs prevent splitting of narrow wooden profiles
- Asymmetrical single thread for maximum reliability
- Optimal matching of drill tip and thread geometry
- Excellent anchoring in wood due to asymmetrical thread flanks
Professional Installation Requirements
- Recommended installation by professionals familiar with wood screw applications to ensure precise positioning and secure fastening.
Applications
- Furniture assembly
- Cabinet making
- Store construction
- Exhibition stand construction
- Interior fitting
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- RoHS-compliant ensuring reduced hazardous substances
- Durable hardened steel construction extends product life reducing waste
Warranty Information
Comes with ETA-11/0190 approval and RoHS compliance ensuring quality and safety standards.
Available Now
The Wurth ASSYplus 4 TH glass strip screw is available for immediate purchase, ideal for furniture and interior construction applications.
