ATS 3P 160A Type B 160A Frame NXZM Chint

BRAND: CABAC
SKU: 256790
$3,052.50 List price: $4,070.00
+ −
30 Days Return Electricians Unlock Trade Access
Chint NXZM 160A 3P ATS features CB class changeover, Type B intelligent controller and 160A frame. Ideal for mains-generator changeover.

Alternatively Known As: CHINT NXZM-160/3B ATS, 160A 3-Pole Changeover Switch, Mains-Generator Transfer Switch

Technical Specifications
  • Series: NXZM
  • Frame Current: 160 A
  • Rated Operational Current: 160 A
  • Number of Poles: 3P
  • Equipment Class: CB circuit-breaker type
  • Controller: Type B intelligent controller
  • Rated Operational Voltage: 400/415 V AC
  • Rated Frequency: 50/60 Hz
  • Rated Control Supply Voltage: 230/240 V AC
  • Rated Insulation Voltage: 800 V AC
  • Rated Impulse Withstand Voltage: 8 kV
  • Utilisation Category: AC-33B
  • Operating Transfer Time: Approximately 3.3 seconds
  • Ingress Protection: IP30
  • Operating Temperature: -5 °C to +40 °C
  • Mechanical Endurance: 8,000 operations
  • Electrical Endurance: 2,000 operations
  • Short-Circuit Rating: 35 kA for S version or 50 kA for H version at 400 V AC
  • Installation: Surface mounting with cable or busbar connection
  • Dimensions (H x L x W): 250mm x 345mm x 195mm
  • Weight: 7.5 kg
Key Features
  • Automatic transfer between normal and standby power sources
  • Suitable for mains-generator and mains-mains changeover applications
  • CB class transfer equipment using integrated circuit-breaker switching devices
  • Type B intelligent controller with monitoring and configurable transfer functions
  • Supports automatic transfer and automatic restoration operation
  • Adjustable undervoltage, overvoltage and transfer delay settings
  • Generator control and fire-control interface functions
  • Manual and automatic operating modes with mechanical interlocking
  • Designed for three-phase low-voltage power distribution systems
Professional Installation Requirements
  • Installation, commissioning and connection to mains or generator supplies must be performed by a licensed electrician in accordance with the manufacturer’s instructions, AS/NZS 3000 and, where generator systems are involved, AS/NZS 3010.
Applications
  • Mains-generator automatic changeover systems
  • Standby power distribution
  • Commercial buildings and industrial facilities
  • High-rise and infrastructure power systems
  • Automatic transfer of critical electrical loads
  • Generator-backed HVAC, refrigeration, communications and process equipment
Standards & Compliance
  • AS/NZS IEC 60947.6.1:2015 for low-voltage transfer switching equipment
  • AS/NZS 3000 for electrical installation and wiring requirements
  • AS/NZS 3010 for electrical installations incorporating generating sets
Environmental Benefits
  • Long mechanical and electrical service life helps reduce replacement frequency and equipment waste
  • Supports controlled transfer between grid and generator supplies, helping reduce unnecessary generator operation
  • Metal and copper electrical components can be recovered through appropriate electrical equipment recycling streams
Warranty Information

CHINT low-voltage apparatus is generally covered against defects in materials and workmanship for 27 months from the date of manufacture when supplied through authorised sales channels, subject to the applicable sales contract and Australian Consumer Law.

Available Now

Available through authorised CHINT distributors in Australia.
