Ausrack IP66 Cabinet 2000x600x600mm | 316 Stainless Steel | Dust & Water Protection by B&R Enclosures

SKU: ARIP42U66/S
$10,471.20 List price: $13,161.20
Free pick up (over 25 kg)
For delivery quote message
Ausrack IP66 cabinet with 2000x600x600mm dimensions and 316 stainless steel construction—ideal for data centers and telecommunications. Built for harsh environments, offering dust and water protection with easy cabling and secure locking.

Product Name/Title: Ausrack IP S/S Encl 2000X600X600mm

Brand: B&R Enclosures

SKU: ARIP42U66/S

Alternatively Known As: Ausrack IP66 Cabinet, 316 Stainless Steel Cabinet, Data Cabinet

Technical Specifications
  • Material: 1.5mm 316 stainless steel or 1.6mm zinc coated steel.
  • IP Rating: IP66.
  • Height: 2000mm.
  • Width: 600mm.
  • Depth: 600mm.
  • Part Number: ARIP42U66/S.
  • Dimensions (H x L x W): 2000mm x 600mm x 600mm
  • Weight: 50 kg
Key Features
  • 19” cabinet system designed to protect sensitive equipment from harsh environments.
  • Suitable for protecting equipment from dust and water.
  • Designed to accommodate small to medium passive patching networks.
  • Easy cabling via gland plate.
  • Manufactured from 1.6mm zinc coated steel or 1.5mm 316 stainless steel.
  • ASSDA approved N4 surface finish.
  • Front and rear adjustable 19″ rack rails.
  • Gland plate (fitted internally or externally).
  • 7mm square turnbuckle lock.
  • Lockable L handles.
  • 3-point locking.
  • Removable back.
  • Door rails.
  • Earth strap kit.
Professional Installation Requirements
  • Professional installation is recommended to ensure proper setup and safety.
Applications
  • Data centers: Protecting sensitive equipment from harsh environments.
  • Telecommunications: Suitable for small to medium passive patching networks.
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Ausrack IP – 316SS Cabinet System is available now for immediate purchase. Ideal for data centers and telecommunications applications.
