Auto Bypass Switch ATS Rack Mount 1Ph 10A with PDU PSS

BRAND: CABAC
SKU: EMBP-PDU-10A
$414.70 List price: $552.90
+ −
30 Days Return Electricians Unlock Trade Access
PSS external bypass features manual bypass plus automatic transfer switch, 1 phase 10A, integrated PDU and rack or wall mount. Ideal for 1-2.2kVA UPS systems.

Alternatively Known As: PSS External Bypass ATS PDU, PSS 10A UPS Bypass Switch, PSS Rack-Mount UPS Maintenance Bypass

Technical Specifications
  • Model: EMBP-PDU-10A
  • Electrical Configuration: Single-phase, 10A
  • UPS Compatibility: 1–2.2kVA UPS systems
  • Functions: External manual bypass and automatic transfer switch
  • PDU Outputs: 10A Australian socket outlets
  • Indicators: Red LED for mains power; red and green LEDs for UPS power
  • Connections: Long mains cable and short UPS output cable with blue identification tag
  • Mounting: Rack, wall or UPS mount
  • Installation Requirement: UPS input and PDU mains input must operate from the same circuit
  • Dimensions (H x L x W): 62mm x 482.5mm x 47mm
  • Weight: 1.2 kg
Key Features
  • Combines manual UPS bypass and automatic transfer switching in one PDU-style enclosure
  • Automatically transfers the load to mains power if UPS power fails or becomes unavailable
  • Provides a controlled method for removing or servicing the UPS without disconnecting the load
  • Compatible with 1–2.2kVA UPS systems using the correct plug types
  • Suitable for rack, wall or UPS mounting
  • LED status indication distinguishes mains and UPS operation
  • Push-button control for transferring the load and disconnecting the UPS
Professional Installation Requirements
  • Mains-connected equipment should be installed and commissioned by a licensed electrician or suitably qualified UPS technician. Installation must follow the manufacturer’s instructions, including operation of the UPS input and PDU mains input from the same circuit and compliance with AS/NZS 3000.
Applications
  • UPS maintenance and replacement without extended interruption to connected equipment
  • Small server racks and network cabinets
  • Telecommunications and communications equipment
  • Security, control and other critical low-power systems
  • 1–2.2kVA single-phase UPS installations
Standards & Compliance
  • AS/NZS 3000:2018 – Electrical installations and wiring requirements
  • AS/NZS IEC 60947.6.1:2015 – Applicable transfer switching equipment standard
Environmental Benefits
  • Extends the practical service life of compatible UPS systems by simplifying maintenance and replacement
  • Reusable switching and PDU assembly can reduce replacement-related electrical waste
  • Metal mounting hardware and enclosure components are generally recoverable through appropriate electrical equipment recycling streams
Warranty Information

PSS standard warranty is a 2-year return-to-base warranty from the original purchase date, subject to PSS warranty terms and installation in accordance with manufacturer instructions and applicable Australian standards.

Available Now

Available through PSS and authorised Australian electrical, UPS and power-distribution distributors.
