Automatic Transfer Switch PDU | 3.84 kW | 16A Input | 8 C13 & 1 C19 Outlets | Eaton
Automatic transfer switch PDU with 3.84 kW power capacity and dual C20 inputs—ideal for data centers and IT equipment power management. Built for seamless power redundancy, featuring a compact 1U rack form factor and network management capabilities.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Automatic Transfer Switch PDU | 3.84 kW | 16A Input | 8 C13 & 1 C19 Outlets | Eaton
Brand: Eaton
SKU: 9001-5018
Alternatively Known As: Automatic Transfer Switch PDU, Rack ATS Power Distribution Unit, Eaton Networked ATS PDU
Technical Specifications
- Power Wattage: 3.84 kW max
- Input Voltage: 200-240V
- Amperage Rating: 16A
- Frequency Rating: 50/60 Hz
- Input Connection: (2) C20
- Outlets: (8) C13, (1) C19
- Phase: Single-phase
- Operating Temperature: 0° to 40°C (32° to 104°F)
- Mounting Direction: Horizontal
- Cord Length: 2m
- Over Voltage Category: 2
- Communication Protocols: HTTP, HTTPS, SSL, Telnet, FTP, SNMP, SMTP, DNS, DHCP, LDAP, RADIUS
- Display: LED indication and Ampere Meter
- Dimensions (H x L x W): 43mm x 430mm x 250mm
- Weight: 3.54 kg
Key Features
- Provides power redundancy to IT equipment
- Compact 1U rack form factor
- Seamlessly switches from one power source to another
- Network management LCD with metering and basic configuration capabilities
- Supports SNMP and Ethernet interface for remote management
- Includes mounting materials and input cables
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and optimal operation.
Applications
- Data centers and server rooms requiring power redundancy
- IT equipment power management
- Rack-mounted network and communication equipment
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Reduces downtime and energy waste by ensuring continuous power supply
- Compact design minimizes material usage and rack space
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton ATS w/Network Card with dual C20 inputs and multiple C13 and C19 outlets is available now for immediate purchase. Ideal for data centers and IT rack power redundancy applications.
