Auxiliary Contact 1NO 1NC | 250V Rated | Front Mount by NHP
Auxiliary contact with 1NO and 1NC configuration, rated for 250V—ideal for motor protection and control systems. Built for industrial and commercial use, with front mount design for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 140MT Auxiliary Contact with 1NO Contact and 1NC Contact Front Mount
Brand: NHP
SKU: 140MTCAFA11
Alternatively Known As: 140MTCAFA11, Auxiliary Contact Block, Motor Protection Contact
Technical Specifications
- Number of Contacts: 1 NO, 1 NC
- Rated Insulation Voltage: 250 V
- Rated Operation Current at 40°C: 5 A
- Rated Operation Current at AC 15 (24 V): 4 A
- Rated Operation Current at AC 15 (120 V): 3 A
- Rated Operation Current at AC 15 (240 V): 1.5 A
- Rated Operation Current at DC 13 (24 V): 1.2 A
- Rated Operation Current at DC 13 (125 V): 0.22 A
- Rated Operation Current at DC 13 (250 V): 0.11 A
- Mounting Method: Front fastening
- Dimensions (H x L x W): 50mm x 100mm x 50mm
- Weight: 0.3 kg
Key Features
- 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration.
- Rated insulation voltage of 250 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor protection and control systems
- Commercial: Equipment requiring auxiliary contacts for operational safety
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Enhances safety in motor control applications, reducing the risk of equipment failure.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 140MT Auxiliary Contact is available now for immediate purchase, ideal for motor protection applications.
