Auxiliary Contact 1NO 1NC | 690V Insulation | Top Mount by NHP
Auxiliary contact with 1NO and 1NC configuration, rated for 690V insulation—ideal for control panels and automation systems. Built for industrial and commercial use, with top mounting for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 100K Auxiliary Contact with 1NO Contact and 1NC Contact Front Mount
Brand: NHP
SKU: 100KFC11
Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact
Technical Specifications
- Number of contacts: 1 NO, 1 NC
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15, 24 V: 3 A
- Rated operation current at AC 15, 120 V: 3 A
- Rated operation current at AC 15, 240 V: 2 A
- Rated operation current at AC 15, 400 V: 1.2 A
- Rated operation current at DC 13, 24 V: 2.3 A
- Rated operation current at DC 13, 110 V: 0.55 A
- Rated operation current at DC 13, 220 V: 0.27 A
- Minimum contact rating current: 2 mA
- Minimum contact rating voltage: 15 V
- Rated operation current at AC 15, 230 V: 2 A
- Mounting method: Top mounting
- Dimensions (H x L x W): 50mm x 100mm x 50mm
- Weight: 0.5 kg
Key Features
- 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration.
- Rated insulation voltage of 690 V.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control panels, machinery, and automation systems
- Commercial: HVAC systems, lighting control, and motor control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Designed for energy efficiency in control systems.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100K Auxiliary Contact with 1NO and 1NC Contact is available now for immediate purchase. Ideal for industrial and commercial applications.
