Auxiliary Contact 1NO 3NC | 690V Insulation | Top Mount by NHP

BRAND: NHP
SKU: CS8P13E
$92.40 List price: $122.70
+ −
30 Days Return Delivery Options
Auxiliary contact with 1NO and 3NC contacts, rated for 690V insulation—ideal for industrial and commercial control systems. Built for easy top mounting, ensuring reliable performance in automation and building management.

Product Name/Title: S+S CS8 Auxiliary Contact with 1NO Contact and 3NC Contact

Brand: NHP

SKU: CS8P13E

Alternatively Known As: Auxiliary Contact Block, Control Relay Contact

Technical Specifications
  • Number of Contacts: 1 NO, 3 NC
  • Rated Insulation Voltage: 690 V
  • Rated Operation Current at 40°C: 10 A
  • Rated Operation Current at AC 15 24 V: 3 A
  • Rated Operation Current at AC 15 120 V: 3 A
  • Rated Operation Current at AC 15 240 V: 2 A
  • Rated Operation Current at AC 15 400 V: 1.2 A
  • Rated Operation Current at DC 13 24 V: 2.3 A
  • Rated Operation Current at DC 13 110 V: 0.55 A
  • Rated Operation Current at DC 13 220 V: 0.27 A
  • Min Contact Rating Current: 2 mA
  • Min Contact Rating Voltage: 15 V
  • Rated Operation Current at AC 15 230 V: 2 A
  • Mounting Method: Top mounting
  • Dimensions (H x L x W): 100mm x 75mm x 50mm
  • Weight: 0.5 kg
Key Features
  • 1 Normally Open (NO) contact and 3 Normally Closed (NC) contacts.
  • Rated insulation voltage of 690 V.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Control systems, automation equipment
  • Commercial: Building management systems, machinery control
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The S+S CS8 Auxiliary Contact with 1NO and 3NC Contacts is available now for immediate purchase. Ideal for industrial and commercial control applications.

Non-Returnable & Non-Cancellable

CS8P13E-AU-Control-Relay-Mini-Auxiliary-Contact-Datasheet.pdf (CS8P13E-AU-Control-Relay-Mini-Auxiliary-Contact-Datasheet.pdf, 249 Kb) [Download]
