Auxiliary Contact 2NO 2NC | 690V Insulation | Front Mount by NHP
Auxiliary contact with 2NO and 2NC contacts and 690V insulation—ideal for industrial control panels and automation systems. Built for easy installation with front mount design, ensuring reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 100K Auxiliary Contact with 2NO and 2NC Contacts Front Mount for 100K and 700K
Brand: NHP
SKU: 100KFA22Z
Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact
Technical Specifications
- Number of contacts: 2NO and 2NC
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15 24 V: 3 A
- Rated operation current at AC 15 120 V: 3 A
- Rated operation current at AC 15 240 V: 2 A
- Rated operation current at AC 15 400 V: 1.2 A
- Rated operation current at DC 13 24 V: 2.3 A
- Rated operation current at DC 13 110 V: 0.55 A
- Rated operation current at DC 13 220 V: 0.27 A
- Minimum contact rating current: 2 mA
- Minimum contact rating voltage: 15 V
- Rated operation current at AC 15 230 V: 2 A
- Dimensions (H x L x W): 100mm x 75mm x 50mm
- Weight: 0.5 kg
Key Features
- 2 Normally Open (NO) and 2 Normally Closed (NC) contacts
- Rated insulation voltage of 690 V
- Top mounting method for easy installation
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control panels, machinery, and automation systems
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Designed for energy efficiency and long-lasting performance.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100K Auxiliary Contact is available now for immediate purchase. Ideal for industrial control applications.
