Auxiliary Contact 2NO | 690V Insulation | Top Mounting by NHP
Auxiliary contact with 2 normally open contacts and 690V rated insulation—ideal for industrial control circuits and commercial electrical panels. Built for easy installation with top mounting design.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CA8 Auxiliary Contact with 2NO Contacts
Brand: NHP
SKU: CA8P20
Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact
Technical Specifications
- Number of contacts: 2 NO
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15 24 V: 3 A
- Rated operation current at AC 15 120 V: 3 A
- Rated operation current at AC 15 240 V: 2 A
- Rated operation current at AC 15 400 V: 1.2 A
- Rated operation current at DC 13 24 V: 2.3 A
- Rated operation current at DC 13 110 V: 0.55 A
- Rated operation current at DC 13 220 V: 0.27 A
- Minimum contact rating current: 2 mA
- Minimum contact rating voltage: 15 V
- Rated operation current at AC 15 230 V: 2 A
- Mounting method: Top mounting
- Dimensions (H x L x W): 30mm x 70mm x 50mm
- Weight: 0.5 kg
Key Features
- Mini auxiliary contact with 2 normally open contacts.
- Rated insulation voltage of 690 V.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control circuits, automation systems
- Commercial: Electrical panels, machinery control
Standards & Compliance
- Complies with relevant Australian standards for electrical components.
Environmental Benefits
- Designed for efficient operation in control systems.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP S+S CA8 Auxiliary Contact with 2NO Contacts is available now for immediate purchase. Ideal for industrial and commercial applications.
