Auxiliary Contact Block 1NO 1NC | 690V Rated | Side Mount by NHP
Auxiliary contact block with 1NO and 1NC configuration, rated for 690V—ideal for industrial control circuits and automation systems. Built for easy side mounting, ensuring reliable performance in HVAC and machinery control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Number of Contacts: 1 NO, 1 NC
- Rated Insulation Voltage: 690 V
- Rated Operation Current at 40°C: 16 A
- Rated Operation Current at AC 15 24 V: 6 A
- Rated Operation Current at AC 15 120 V: 6 A
- Rated Operation Current at AC 15 240 V: 4 A
- Rated Operation Current at AC 15 400 V: 3 A
- Rated Operation Current at DC 13 24 V: 3 A
- Rated Operation Current at DC 13 110 V: 0.55 A
- Rated Operation Current at DC 13 220 V: 0.3 A
- Min Contact Rating Current: 50 mA
- Min Contact Rating Voltage: 12 V
- Mounting Method: Side mounting
- Dimensions (H x L x W): 100mm x 50mm x 50mm
- Weight: 0.5 kg
Key Features
- 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration.
- Rated insulation voltage of 690 V.
- Side mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Used in various control circuits and automation systems.
- Commercial: Suitable for HVAC systems and machinery control.
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100E Auxiliary Contact is available now for immediate purchase, ideal for industrial and commercial applications.
