Auxiliary Contact Block 1NO 1NC | 690V Rated | Side Mount by NHP
Auxiliary contact block with 1NO and 1NC configuration and 690V rated insulation—ideal for control panels and automation systems. Built for industrial use, with easy side mounting for quick installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 100E Auxiliary Contact with 1NO Contact and 1NC Contact Side Mount Outside Position
Brand: NHP
SKU: 100ES211
Alternatively Known As: Auxiliary Contact Block, 100E Contact Block
Technical Specifications
- Number of Contacts: 1NO, 1NC
- Rated Insulation Voltage: 690 V
- Rated Operation Current: 16 A at 40°C
- Rated Operation Current at AC 15: 6 A (24V, 120V), 4 A (230V, 240V), 3 A (400V)
- Rated Operation Current at DC 13: 3 A (24V), 0.55 A (110V), 0.3 A (220V)
- Minimum Contact Rating: 50 mA at 12 V
- Mounting Method: Side Mounting
- Dimensions (H x L x W): 100mm x 50mm x 50mm
- Weight: 0.5 kg
Key Features
- 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration.
- Rated insulation voltage of 690 V.
- Side mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control panels, machinery, and automation systems
Standards & Compliance
- Complies with relevant Australian standards for electrical components.
Environmental Benefits
- Designed for energy efficiency and long-lasting performance.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100E Auxiliary Contact is available now for immediate purchase. Ideal for industrial control applications.
