Auxiliary Contact Block 1NO 1NC | 690V Insulation | Side Mount by NHP
Auxiliary contact block with 1NO and 1NC configuration and 690V rated insulation—ideal for control panels and automation systems. Built for industrial and commercial use, with side mounting for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Number of Contacts: 1 NO, 1 NC
- Rated Insulation Voltage: 690 V
- Rated Operation Current at 40°C: 16 A
- Rated Operation Current at AC 15 (24 V): 6 A
- Rated Operation Current at AC 15 (120 V): 6 A
- Rated Operation Current at AC 15 (240 V): 4 A
- Rated Operation Current at AC 15 (400 V): 3 A
- Rated Operation Current at DC 13 (24 V): 6 A
- Rated Operation Current at DC 13 (110 V): 0.55 A
- Rated Operation Current at DC 13 (220 V): 0.3 A
- Minimum Contact Rating Current: 50 mA
- Minimum Contact Rating Voltage: 12 V
- Rated Operation Current at AC 15 (230 V): 4 A
- Mounting Method: Side mounting
- Dimensions (H x L x W): 100mm x 50mm x 50mm
- Weight: 0.5 kg
Key Features
- 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration.
- Rated insulation voltage of 690 V.
- Side mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control panels, machinery, and automation systems
- Commercial: HVAC systems, lighting control, and motor control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100E Auxiliary Contact is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable control solutions.
