Auxiliary Contact Block 1NO 3NC | 690V Insulation | Front Mount by NHP

BRAND: NHP
SKU: 100FA13
$89.50 List price: $118.80
+ −
30 Days Return Delivery Options
Auxiliary contact block with 1NO and 3NC contacts, rated for 690V insulation—ideal for industrial control circuits and commercial electrical panels. Built for easy front mounting, ensuring reliable performance in automation systems.

Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 1NO Contact and 3NC Contact Front Mount

Brand: NHP

SKU: 100FA13

Alternatively Known As: Auxiliary Contact Block, 100C Contact Block

Technical Specifications
  • Number of contacts: 1 NO, 3 NC
  • Rated insulation voltage: 690 V
  • Rated operation current at 40°C: 10 A
  • Rated operation current at AC 15, 24 V: 6 A
  • Rated operation current at AC 15, 120 V: 6 A
  • Rated operation current at AC 15, 240 V: 5 A
  • Rated operation current at AC 15, 400 V: 3 A
  • Rated operation current at DC 12-24 V: 12 A
  • Rated operation current at DC 12-110 V: 3.5 A
  • Rated operation current at DC 12-220 V: 0.55 A
  • Rated operation current at DC 13-24 V: 5 A
  • Rated operation current at DC 13-110 V: 1.2 A
  • Rated operation current at DC 13-220 V: 0.6 A
  • Minimum contact rating current: 5 mA
  • Minimum contact rating voltage: 17 V
  • Rated operation current at AC 15, 230 V: 5.5 A
  • Dimensions (H x L x W): 50mm x 100mm x 100mm
  • Weight: 0.5 kg
Key Features
  • 1 Normally Open (NO) contact and 3 Normally Closed (NC) contacts.
  • Rated insulation voltage of 690 V.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Control circuits, automation systems
  • Commercial: Electrical panels, machinery control
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Auxiliary Contact with 1NO and 3NC contacts is available now for immediate purchase. Ideal for industrial and commercial applications.

Non-Returnable & Non-Cancellable

100FA13-AU-Contactor-Auxiliary-Contact-Datasheet.pdf (100FA13-AU-Contactor-Auxiliary-Contact-Datasheet.pdf, 229 Kb) [Download]
