Auxiliary Contact Block 1NO 3NC | 690V Insulation | Top Mount by NHP
Auxiliary contact block with 1NO and 3NC contacts, rated for 690V insulation—ideal for industrial control panels and automation systems. Built for reliable performance, with top mounting for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Number of Contacts: 1 NO, 3 NC
- Rated Insulation Voltage: 690 V
- Rated Operation Current at 40°C: 10 A
- Rated Operation Current at AC 15 (24V): 3 A
- Rated Operation Current at AC 15 (120V): 3 A
- Rated Operation Current at AC 15 (240V): 2 A
- Rated Operation Current at AC 15 (400V): 1.2 A
- Rated Operation Current at DC 13 (24V): 2.3 A
- Rated Operation Current at DC 13 (110V): 0.55 A
- Rated Operation Current at DC 13 (220V): 0.27 A
- Min Contact Rating Current: 2 mA
- Min Contact Rating Voltage: 15 V
- Rated Operation Current at AC 15 (230V): 2 A
- Mounting Method: Top mounting
- Dimensions (H x L x W): 100mm x 75mm x 50mm
- Weight: 0.5 kg
Key Features
- 1 Normally Open (NO) contact and 3 Normally Closed (NC) contacts.
- Rated insulation voltage of 690 V.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control panels, machinery, and automation systems
- Commercial: HVAC systems, lighting control, and motor control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100K Auxiliary Contact is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable control solutions.
Non-Returnable & Non-Cancellable
