Auxiliary Contact Block 1 NO + 1 NO | 690V | IP20 by Clipsal

BRAND: Clipsal
SKU: VZ20
$79.20 List price: $118.90
+ −
30 Days Return Delivery Options
Auxiliary contact block with 1 NO + 1 NO configuration and 690V rating—ideal for industrial applications. Built for reliability, with IP20 protection and compatibility with TeSys Vario switch bodies.

Product Name/Title: TeSys Mini-Vario, Auxiliary contact block, 1 NO + 1 NO

Brand: Clipsal

SKU: VZ20

Alternatively Known As: TeSys Vario Auxiliary Contact, Auxiliary Contact Block, TeSys Mini-Vario Contact Block

Technical Specifications
  • Rated operational voltage: 690 V AC 50/60 Hz
  • Mechanical durability: 100,000 cycles
  • Electrical durability: 30,000 cycles DC / 1,000,000 cycles AC
  • Connections: screw clamp terminals for 0.75-1.5 mm² flexible and 1-2.5 mm² solid cables
  • IP Rating: IP20 conforming to IEC 60529
  • Rated impulse withstand voltage: 8 kV
  • Conventional free air thermal current: 12 A
  • Conventional enclosed thermal current: 10 A
  • Tightening torque: 0.7 N.m on screw clamp terminals
  • Dimensions (H x L x W): 65mm x 48.5mm x 20mm
  • Weight: 0.05 kg
Key Features
  • 2NO contacts rated for AC operation until 12A/690V and DC operation until 8A/250V.
  • Compatible with TeSys Vario V02 to V6 switch bodies.
  • Multi standards certified (IEC, UL, CSA, CCC, EAC).
  • Green Premium compliant (RoHS/REACh).
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Suitable for use with TeSys Vario switch bodies in various industrial applications.
Standards & Compliance
  • Complies with IEC 60947-5 for safety and performance standards.
Environmental Benefits
  • Green Premium compliant (RoHS/REACh) ensures reduced environmental impact.
Warranty Information

18 months warranty against manufacturing defects.

Available Now

The TeSys Mini-Vario Auxiliary Contact Block is available now for immediate purchase. Ideal for industrial applications requiring reliable contact solutions.

VZ20 (VZ20, 258 Kb) [Download]
