Trade Discount 25%
Auxiliary Contact Block 2NC | 690V Insulation | Top Mount by NHP
Auxiliary contact block with 2 normally closed contacts and 690V rated insulation—ideal for industrial and commercial automation systems. Built for control circuits, with top mounting for easy integration.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CA8 Auxiliary Contact with 2NC Contact
Brand: NHP
SKU: CA8P02
Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact
Technical Specifications
- Number of contacts: 2 NC
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15 24 V: 3 A
- Rated operation current at AC 15 120 V: 3 A
- Rated operation current at AC 15 240 V: 2 A
- Rated operation current at AC 15 400 V: 1.2 A
- Rated operation current at DC 13 24 V: 2.3 A
- Rated operation current at DC 13 110 V: 0.55 A
- Rated operation current at DC 13 220 V: 0.27 A
- Minimum contact rating current: 2 mA
- Minimum contact rating voltage: 15 V
- Mounting method: Top mounting
- Dimensions (H x L x W): 30mm x 60mm x 50mm
- Weight: 0.2 kg
Key Features
- Mini auxiliary contact with 2 normally closed contacts.
- Rated insulation voltage of 690 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control circuits in machinery and equipment
- Commercial: Automation systems and electrical panels
Standards & Compliance
- Complies with relevant Australian standards for electrical components.
Environmental Benefits
- Designed for energy efficiency in control applications.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP S+S CA8 Auxiliary Contact with 2NC Contact is available now for immediate purchase. Ideal for industrial and commercial automation applications.
