Auxiliary Contact Block 2NO 2NC | 690V Insulation | Top Mount by NHP
Auxiliary contact block with 2NO and 2NC contacts, rated for 690V insulation—ideal for industrial control systems and commercial electrical panels. Built for reliability, with top mounting for easy integration.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CS8 Auxiliary Contact with 2NO Contacts and 2NC Contact
Brand: NHP
SKU: CS8P22Z
Alternatively Known As: Auxiliary Contact Block, Control Relay Contact
Technical Specifications
- Number of contacts: 2NO, 2NC
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15, 24 V: 3 A
- Rated operation current at AC 15, 120 V: 3 A
- Rated operation current at AC 15, 240 V: 2 A
- Rated operation current at AC 15, 400 V: 1.2 A
- Rated operation current at DC 13, 24 V: 2.3 A
- Rated operation current at DC 13, 110 V: 0.55 A
- Rated operation current at DC 13, 220 V: 0.27 A
- Min contact rating current: 2 mA
- Min contact rating voltage: 15 V
- Mounting method: Top mounting
- Dimensions (H x L x W): 50mm x 100mm x 50mm
- Weight: 0.5 kg
Key Features
- Mini auxiliary contact with 2 normally open and 2 normally closed contacts.
- Rated insulation voltage of 690 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control systems, automation equipment
- Commercial: Electrical panels, machinery control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient design contributes to reduced energy consumption in control systems.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Auxiliary Contact with 2NO and 2NC Contacts is available now for immediate purchase. Ideal for industrial and commercial control applications.
