Auxiliary Contact Block 2NO | 690V Insulation | Top Mount by NHP

BRAND: NHP
SKU: 100FA20
$45.30 List price: $60.20
+ −
30 Days Return Delivery Options
Auxiliary contact block with 2 normally open contacts and 690V rated insulation—ideal for industrial and commercial electrical systems. Built for versatile control, with top mounting for easy installation.

Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 2NO Contact Front Mount

Brand: NHP

SKU: 100FA20

Alternatively Known As: Auxiliary Contact Block, 100C Contact, Front Mount Auxiliary Contact

Technical Specifications
  • Number of Contacts: 2 NO
  • Rated Insulation Voltage: 690 V
  • Rated Operation Current at 40°C: 10 A
  • Rated Operation Current at AC 15 (24 V): 6 A
  • Rated Operation Current at AC 15 (120 V): 6 A
  • Rated Operation Current at AC 15 (240 V): 5 A
  • Rated Operation Current at AC 15 (400 V): 3 A
  • Rated Operation Current at DC (12-24 V): 12 A
  • Rated Operation Current at DC (12-110 V): 3.5 A
  • Rated Operation Current at DC (12-220 V): 0.55 A
  • Rated Operation Current at DC (13-24 V): 5 A
  • Rated Operation Current at DC (13-110 V): 1.2 A
  • Rated Operation Current at DC (13-220 V): 0.6 A
  • Minimum Contact Rating Current: 5 mA
  • Minimum Contact Rating Voltage: 17 V
  • Rated Operation Current at AC 15 (230 V): 5.5 A
  • Mounting Method: Top mounting
  • Dimensions (H x L x W): 100mm x 75mm x 50mm
  • Weight: 0.5 kg
Key Features
  • 2 Normally Open (NO) contacts for versatile control options.
  • Rated insulation voltage of 690 V for high voltage applications.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Used in various industrial applications for controlling electrical circuits.
  • Commercial: Suitable for commercial electrical systems requiring auxiliary contacts.
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Auxiliary Contact with 2NO Contact Front Mount is available now for immediate purchase. Ideal for industrial and commercial electrical systems.

100FA20-AU-Contactor-Auxiliary-Contact-Datasheet.pdf (100FA20-AU-Contactor-Auxiliary-Contact-Datasheet.pdf, 229 Kb) [Download]
