Auxiliary Contact Block 3NO 1NC | 690V Insulation | Front Mount by NHP
Auxiliary contact block with 3 normally open and 1 normally closed contact—ideal for control panels and automation systems. Built for industrial and commercial use, with 690V insulation and easy front mount installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 3NO Contacts and 1NC Contact Front Mount
Brand: NHP
SKU: 100FA31
Alternatively Known As: Auxiliary Contact Block, 100C Contact Block
Technical Specifications
- Number of NO contacts: 3
- Number of NC contacts: 1
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15, 24 V: 6 A
- Rated operation current at AC 15, 120 V: 6 A
- Rated operation current at AC 15, 240 V: 5 A
- Rated operation current at AC 15, 400 V: 3 A
- Rated operation current at DC 12-24 V: 12 A
- Rated operation current at DC 12-110 V: 3.5 A
- Rated operation current at DC 12-220 V: 0.55 A
- Rated operation current at DC 13-24 V: 5 A
- Rated operation current at DC 13-110 V: 1.2 A
- Rated operation current at DC 13-220 V: 0.6 A
- Minimum contact rating current: 5 mA
- Minimum contact rating voltage: 17 V
- Rated operation current at AC 15, 230 V: 5.5 A
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 0.5 kg
Key Features
- 3 Normally Open (NO) contacts and 1 Normally Closed (NC) contact.
- Rated insulation voltage of 690 V.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control panels, machinery, and automation systems
- Commercial: Electrical installations requiring auxiliary contacts
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100C Auxiliary Contact with 3NO and 1NC Contact is available now for immediate purchase. Ideal for industrial and commercial electrical applications.
