Auxiliary Contact Block 3NO + 1NC | 690V AC | Screw Clamp Terminals by Clipsal
Auxiliary contact block with 3NO + 1NC configuration and 690V AC rating—ideal for industrial applications. Built for high reliability, with front mounting and screw clamp terminals.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated operational voltage: 690 V AC.
- Rated insulation voltage: 690 V conforming to IEC 60947-5-1.
- Conventional free air thermal current: 10 A (at 50 °C).
- Minimum switching current: 5 mA.
- Minimum switching voltage: 17 V.
- IP Rating: IP20 conforming to IEC 60529.
- Dimensions (H x L x W): 30mm x 35mm x 38mm
- Weight: 0.1 kg
Key Features
- 3NO + 1NC contacts rated up to 10A 690V AC.
- Connection by screw clamp terminals.
- Front mounting by clip-on design.
- High reliability and durability.
- Multi standards certified (IEC, UL, CSA, CCC).
- Green Premium compliant (RoHS/REACh).
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Suitable for use with contactors in various industrial applications.
Standards & Compliance
- Complies with AS/NZS 60947 for safety and performance standards.
Environmental Benefits
- Green Premium compliant (RoHS/REACh).
Warranty Information
Standard warranty applies.
Available Now
The TeSys K Auxiliary Contact Block is available now for immediate purchase. Ideal for industrial applications requiring reliable contact solutions.
