Auxiliary Contact Block 4NO 10A 690VAC 30x35x38mm Clipsal

BRAND: Clipsal
SKU: SCHLA1KN40
$60.80 List price: $75.80
+ −
30 Days Return Electricians Unlock Trade Access
Clipsal Auxiliary Contact Block AC Front Mounting features 690V AC, 690V and 10A. 4NO contacts rated up to 10A 690V AC. Ideal for used with contactors LC.
Technical Specifications
  • Rated operational voltage: 690 V AC
  • Rated insulation voltage: 690 V
  • Conventional free air thermal current: 10 A (at 50 °C)
  • Insulation resistance: > 10 MOhm
  • IP Rating: IP20
  • Operating altitude: 2000 m
  • Dimensions (H x L x W): 30mm x 35mm x 38mm
  • Weight: 0.1 kg
Key Features
  • 4NO contacts rated up to 10A 690V AC
  • Connection by screw clamp terminals
  • Front mounting by clip-on
  • High reliability and durability
Professional Installation Requirements
  • Professional installation is recommended for optimal performance.
Applications
  • Industrial: Used with contactors LC.K, LP.K, CA.K
Standards & Compliance
  • Complies with IEC, UL, CSA, CCC standards.
Environmental Benefits
  • Green Premium compliant (RoHS/REACh)
Warranty Information

Standard warranty applies.

Available Now

The TeSys K Auxiliary Contact Block is available now for immediate purchase. Ideal for industrial applications.

LA1KN40 (LA1KN40, 219 Kb) [Download]
