Auxiliary Contact Block 4NO | 690V Insulation | Top Mount by NHP
Auxiliary contact block with 4 normally open contacts and 690V insulation—ideal for industrial automation and control panels. Built for versatile applications, with top mounting for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 4NO Contacts Front Mount
Brand: NHP
SKU: 100FA40
Alternatively Known As: Auxiliary Contact Block, 100C Contact Block
Technical Specifications
- Number of contacts: 4 NO
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15 (24 V): 6 A
- Rated operation current at AC 15 (120 V): 6 A
- Rated operation current at AC 15 (240 V): 5 A
- Rated operation current at AC 15 (400 V): 3 A
- Rated operation current at DC (12-24 V): 12 A
- Rated operation current at DC (12-110 V): 3.5 A
- Rated operation current at DC (12-220 V): 0.55 A
- Rated operation current at DC (13-24 V): 5 A
- Rated operation current at DC (13-110 V): 1.2 A
- Rated operation current at DC (13-220 V): 0.6 A
- Minimum contact rating current: 5 mA
- Minimum contact rating voltage: 17 V
- Rated operation current at AC 15 (230 V): 5.5 A
- Mounting method: Top mounting
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 0.5 kg
Key Features
- 4 Normally Open (NO) contacts for versatile applications.
- Rated insulation voltage of 690 V for high-performance use.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: Electrical installations requiring auxiliary contacts
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Designed for energy efficiency and long-lasting performance.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100C Auxiliary Contact with 4NO Contacts Front Mount is available now for immediate purchase. Ideal for industrial and commercial electrical installations.
