S+S CA8 Auxiliary Contact with 4NO Contacts

Auxiliary Contact Block 4NO | 690V Rated | Top Mount | Compact by NHP

BRAND: NHP

SKU: CA8P40

$95.40 List price: $126.70

+ −

30 Days Return Delivery Options

Auxiliary contact block with 4 normally open contacts and 690V rated insulation—ideal for industrial automation and control panels. Built for versatile applications, with top mounting for easy installation.

Description
Attachments

Product Name/Title: S+S CA8 Auxiliary Contact with 4NO Contacts

Brand: NHP

SKU: CA8P40

Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact

Technical Specifications

Rated Insulation Voltage (Ui): 690 V
Rated Operation Current (Ie) at 40°C: 10 A
Rated Operation Current (Ie) at AC 15 24 V: 3 A
Rated Operation Current (Ie) at AC 15 120 V: 3 A
Rated Operation Current (Ie) at AC 15 240 V: 2 A
Rated Operation Current (Ie) at AC 15 400 V: 1.2 A
Rated Operation Current (Ie) at DC 13 24 V: 2.3 A
Rated Operation Current (Ie) at DC 13 110 V: 0.55 A
Rated Operation Current (Ie) at DC 13 220 V: 0.27 A
Minimum Contact Rating Current: 2 mA
Minimum Contact Rating Voltage: 15 V
Rated Operation Current (Ie) at AC 15 230 V: 2 A
Dimensions (H x L x W): 100mm x 75mm x 50mm
Weight: 0.5 kg

Key Features

4 Normally Open (NO) contacts for versatile applications.
Top mounting method for easy installation.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Automation systems, control panels
Commercial: Electrical installations requiring auxiliary contacts

Standards & Compliance

Complies with AS/NZS 60950 for safety and performance standards.

Environmental Benefits

Designed for energy efficiency in electrical systems.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The S+S CA8 Auxiliary Contact with 4NO Contacts is available now for immediate purchase. Ideal for industrial and commercial electrical installations.

CA8P40-AU-Contactor-Mini-Auxiliary-Contact-Datasheet.pdf (CA8P40-AU-Contactor-Mini-Auxiliary-Contact-Datasheet.pdf, 259 Kb) [Download]
