Auxiliary Contact Block 4NO | Top Mount | 690V Rated by NHP
Auxiliary contact block with 4 normally open contacts and top mounting—ideal for industrial and commercial control systems. Built for versatile control options, with 690V rated insulation voltage for reliable performance.
Sign in
Please login to continue to your account.
Product Name/Title: S+S CS7 Auxiliary Contact with 4NO Contacts Top Mount
Brand: NHP
SKU: CS7PV40
Alternatively Known As: Auxiliary Contact Block, Control Relay Contact
- Number of Contacts: 4 NO
- Rated Insulation Voltage: 690 V
- Rated Operation Current (AC 15, 240 V): 5 A
- Rated Operation Current (DC 12, 24 V): 12 A
- Min Contact Rating Current: 5 mA
- Mounting Method: Top mounting
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 0.5 kg
- 4 Normally Open (NO) contacts for versatile control options.
- Top mounting design for easy installation.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Industrial: Control systems, automation equipment
- Commercial: Electrical panels, machinery control
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
- Designed for energy efficiency in control systems.
1 year warranty against manufacturing defects.
The S+S CS7 Auxiliary Contact with 4NO Contacts Top Mount is available now for immediate purchase. Ideal for industrial and commercial control applications.
