PL 16 / 25 (3300) B2B 4P Insulator and Contact Set

B2B 4P Insulator and Contact Set | 660V to 3300V | 300A to 425A | IP55 by Ausproof

BRAND: Ausproof

SKU: RS2652

$541.80 List price: $672.90

+ −

30 Days Return Delivery Options

B2B 4P insulator and contact set with operating voltage from 660V to 3300V and current rating of 300A to 425A—ideal for mining and hazardous environments. Built for durability with stainless steel construction and quick release features, ensuring reliable performance in tough conditions.

Description

Product Name/Title: PL 16 / 25 (3300) B2B 4P Insulator and Contact Set

Brand: Ausproof

SKU: RS2652

Alternatively Known As: PL Range Insulator Set, Ex-certified 4 Pin Contact Set, Flameproof Electrical Connector, Mining Electrical Connector

Technical Specifications

Operating Voltage: 660V to 3300V
Current Rating: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Plug Weight: 9.0 kg
Receptacle Weight: 10.7 kg
Dimensions (H x L x W): 330mm x 400mm x 250mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by qualified personnel trained in hazardous area electrical equipment installation to ensure compliance with safety standards.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairable design minimizes waste by allowing on-site repairs
Lightweight design reduces material usage and transportation emissions

Warranty Information

Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.

Available Now

The Ausproof PL 16 / 25 (3300) B2B 4P Insulator and Contact Set is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring flameproof electrical connectors.
