PL 16 / 25 (11/3300) B2B 6P Insulator and Contact Set

B2B 6P Insulator and Contact Set | 660V to 3300V | 300A & 425A Ratings | IP55 Protection by Ausproof

BRAND: Ausproof

SKU: RS2653

$774.10 List price: $961.50

+ −

30 Days Return Delivery Options

B2B 6P insulator and contact set with a voltage range of 660V to 3300V and current ratings of 300A and 425A—ideal for mining and hazardous environments. Built for professional installation, it features durable stainless steel construction and quick release for easy termination.

Description

Product Name/Title: PL 16 / 25 (11/3300) B2B 6P Insulator and Contact Set

Brand: Ausproof

SKU: RS2653

Alternatively Known As: PL Range Insulator Set, Back-to-Back 6 Pin Contact Set, Ex Certified Electrical Connector, Mining Grade Insulator Set

Technical Specifications

Voltage Range: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Plug Weight: 9.0 kg
Receptacle Weight: 10.7 kg
Dimensions (H x L x W): 400mm x 350mm x 300mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Professional installation by qualified electricians trained in hazardous area electrical equipment is required to ensure safety and compliance.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Easy flameproof repair reduces waste and downtime.

Warranty Information

Warranty details available upon request from Ausproof, typically covering manufacturing defects.

Available Now

The Ausproof PL 16 / 25 (11/3300) B2B 6P Insulator and Contact Set is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
