BF Multi Frames Extension | 1m x 600mm Cross Bars | Adjustable Height | 500kg Load Capacity | by Aspen Pumps
The BF Multi Frames Extension is designed for versatile support of air conditioning units, featuring 1m x 600mm cross bars and adjustable height for customized installation. Ideal for both residential and commercial applications, this extension kit ensures stability with 305mm feet and includes clamp kits for secure assembly, promoting optimal system performance and energy efficiency.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: BF Multi Frames Extension | 1m x 600mm Cross Bars | Adjustable Height | 500kg Load Capacity | by Aspen Pumps
Brand: Aspen Pumps
SKU: B9721-Narrow
Alternatively Known As: Multi Frame Extension Kit, Multi Frame XL Extension Bars, A/C Support Frame Extension
Technical Specifications
- Length: 1000 mm
- Width: 1200 mm
- Height adjustable: 335 - 660 mm
- Weight: 28 kg
- Maximum load capacity: 500 kg
- Includes clamp kits for secure assembly
- Dimensions (H x L x W): 335mm x 1000mm x 1200mm
- Weight: 28 kg
Key Features
- 305mm feet for stable support
- Compatible with any Multi Frame and Multi Frame XL of the same height
- Extendable from any side for flexible installation
- Adjustable leg assemblies for height customization
- Easy assembly with cross bars positioning onto end bars
- Supplied boxed with clamp kits
Professional Installation Requirements
- Professional installation by qualified technicians is recommended to ensure proper assembly and secure support of air conditioning units.
Applications
- Supports and extends Multi Frame and Multi Frame XL air conditioning units
- Suitable for various A/C unit installations requiring frame size and shape customization
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Enables efficient installation and support of air conditioning units, promoting optimal system performance and energy efficiency
Warranty Information
Standard manufacturer warranty applies. Please refer to Aspen Pumps warranty policy for details.
Available Now
The Aspen Pumps BF Multi Frames Extension Kit is available for immediate purchase, ideal for extending and customizing A/C support frames in residential and commercial installations.
