Bi-Metal Circuit Breaker Lug 120mm² | 10mm Stud | Friction Welded & Sealed Crimping by Cabac
Cabac Bi-Metal Circuit Breaker Lug 120mm² with 10mm stud offers a strong, reliable connection for aluminium and copper conductors using friction welding and sealed crimping compound.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Bi-Metal Circ Break Lug 120mm2 10mm Stud
Brand: Cabac
SKU: BL120CB-10
Alternatively Known As: Bi-Metal Lug, Circuit Breaker Lug, Bi-Metallic Lug, Electrical Lug Connector
Technical Specifications
- Conductor Size: 120mm²
- Stud Size: 10mm
- Manufacturing Process: Friction welding
- Suitable for aluminium and copper conductors
- Crimping compound sealed with cap
- Crimping positions clearly marked on barrel
- Dimensions (H x L x W): 10mm x 120mm x 30mm
- Weight: 0.1 kg
Key Features
- Manufactured using friction welding process producing a very strong electrically sound joint
- Suitable for aluminium conductor and copper circuit breaker terminals
- Crimp from palm end to force compound into conductor strands
- Crimping compound in barrel and sealed with cap
- Crimping positions, AF, clearly marked on barrel
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure proper crimping and secure electrical connections.
Applications
- Electrical power connectivity for aluminium and copper conductors
- Circuit breaker terminal connections in residential, commercial, and industrial electrical systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces need for frequent replacements, minimizing waste
- Efficient electrical connection reduces energy loss
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty policy for details.
Available Now
The Cabac Bi-Metal Circuit Breaker Lug 120mm² 10mm Stud is available for immediate purchase, ideal for electrical power connectivity applications in residential, commercial, and industrial settings.
