Bi-Metal Lug 120mm2-LPB | Aluminium & Copper | Friction Welded Joint | Extended Barrel Length | @EA of 1 | by Cabac
The Bi-Metal Lug 120mm2-LPB is designed for secure electrical power connectivity, featuring a strong friction welded joint made from high-quality aluminium and copper. Ideal for CCT cable installations, this lug minimizes contact resistance and corrosion, ensuring reliable performance in overhead aluminium conductor systems. Its extended barrel length allows for additional crimping positions, making it versatile for various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: Aluminium (99.6%) and Copper (99.9%)
- Manufacturing Process: Friction welded joint
- Palm Length: Variable, unfinished for cropping and drilling
- Barrel Length: Extended with additional crimping position
- Surface Treatment: Chemically treated barrels with jointing compound
- Compatibility: Designed for CCT conductors with polyethylene covering and water blocking compound
- Crimping: Suitable for standard Australian tooling
- Dimensions (H x L x W): 15mm x 120mm x 40mm
- Weight: 0.15 kg
Key Features
- Manufactured using friction welding process producing a very strong electrically sound joint
- Compound reduces contact resistance and inhibits corrosion
- Crimp from palm end to force compound into conductor strands
- Suitable for CCT cable installations
- Long barrel length with additional crimping position for secure connection
- Palm length can be cropped and drilled to individual requirements
Professional Installation Requirements
- Installation should be performed by a qualified electrician experienced with crimping and connecting CCT conductors to ensure secure and compliant connections.
Applications
- Electrical power connectivity for overhead aluminium conductors
- Suitable for CCT (Covered Conductor Thick) cable installations
- Used in electrical distribution and transmission systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Reduces corrosion and extends service life of electrical connections
- Minimizes flashover and vegetation clearance requirements, reducing environmental impact
- Supports use of CCT conductors which reduce wildlife interference
Warranty Information
Standard manufacturer warranty against defects applies. Please refer to Cabac warranty policy for details.
Available Now
The Cabac Bi-Metal Lug 120mm2-LPB is available for immediate purchase, ideal for electrical power connectivity in overhead aluminium conductor installations.
