Bi-Metal Sector Link | Aluminium to Copper | Friction Welded Joint | 110 MPa Tensile Strength by Cabac
The Cabac Bi-Metal Sector Link 70/3/50 is designed to link solid or standard sector aluminium cable to circular copper cable, featuring a strong friction welded joint and compliance with Australian and international standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Bi-Metal Sector Link 70/3/50
Brand: Cabac
SKU: BLKS70-3-50
Alternatively Known As: Bi-Metal Cable Link, Aluminium to Copper Sector Link, Bi-Metallic Sector Connector
Technical Specifications
- Conductive material: Aluminium sleeve 99.6%, Copper palm 99.95%
- Tensile strength: 110 MPa
- Ductile rating: 28%
- Final metal state: Fully annealed including joint
- Joining method: Friction welding (IEC standard)
- Cable sector shape: BS3988-1970
- Operating temperature: -40°C to 125°C
- Electrical resistivity: Aluminium max 2.6 micro-ohm cm, Copper 1.738 micro-ohm cm
- Conductivity: Aluminium 61.8% IACS (min.), Copper 99.7% IACS
- Conformant standards: AS4325 Part 1 Australia, IEC France, DIN/VDE Germany, JIS Japan, BS United Kingdom
- Dimensions (H x L x W): 10mm x 50mm x 70mm
- Weight: 0.2 kg
Key Features
- Manufactured using friction welding process producing a very strong electrically sound joint
- Designed to be crimped with CABAC and MSS Power tools and dies
- Conforms to Australian and many international standards
Professional Installation Requirements
- Installation should be performed by a qualified electrician using appropriate crimping tools to ensure secure and compliant connections.
Applications
- Linking solid or standard sector aluminium cable to circular copper cable in electrical power connectivity
- Suitable for use in energy distribution and rail services
- Ideal for industrial and commercial electrical installations requiring reliable cable connections
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS4325 Part 1 Australia
Environmental Benefits
- Durable construction reduces need for frequent replacements, minimizing waste
- Efficient electrical conductivity reduces energy loss in power transmission
Warranty Information
Warranty details available upon request from manufacturer.
Available Now
The Cabac Bi-Metal Sector Link 70/3/50 is available now for immediate purchase. Ideal for electrical power connectivity applications requiring reliable aluminium to copper cable linking.
