Block and Tackle Pulley System | 750 lbs Max Load | 25' Nylon Rope | Guarded Hook | by Wattmaster
The Block and Tackle Pulley System is designed for lifting and rigging in construction and industrial settings, featuring a maximum safe load of 750 lbs and a durable 25' nylon rope. With lightweight galvanised-steel shell blocks and guarded hooks for added safety, this system is perfect for material handling and general hoisting tasks, ensuring compliance with occupational health and safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Block and Tackle Pulley System | 750 lbs Max Load | 25' Nylon Rope | Guarded Hook | by Wattmaster
Brand: Wattmaster
SKU: A-H1802-30SR
Alternatively Known As: Block and Tackle Pulley, Rope Pulley System, Guarded Hook Block and Tackle, Lifting Pulley System
Technical Specifications
- Rope Diameter: 3/8'' (9.53 mm) nylon rope
- Rope Length: 25' (7.62 m)
- Maximum Safe Load: 750 lbs (340 kg)
- Material: Galvanised-steel shell blocks, aluminium alloy bushings, nylon rope
- Hook Type: Guarded
- Sheaves: Aluminium alloy with all-bronze bushings
- Dimensions (H x L x W): 112mm x 313mm x 114mm
- Weight: 1.3 kg
Key Features
- Light, galvanised-steel shell blocks fitted with snubbing hooks to hold the load
- Strong yet lightweight aluminium alloy sheaves with all-bronze bushings
- 25' (7.62 m) nylon rope spliced to the block
- Hooks designed to fit under insulator and engage pin on cross arm
- Maximum safe load of 750 lbs (340 kg)
- Guarded hook type for added safety
- Made in the USA
Professional Installation Requirements
- Professional installation and use by trained personnel is recommended to ensure safety and compliance with occupational health and safety standards.
Applications
- Lifting and rigging in construction and industrial settings
- Material handling and load securing
- General purpose hoisting and pulling tasks
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste
- Galvanised steel and aluminium alloy components are recyclable
Warranty Information
Standard manufacturer warranty applies. Please refer to Wattmaster for specific warranty details.
Available Now
The Wattmaster Block and Tackle with Guarded Hooks is available for immediate purchase, ideal for lifting and rigging applications in construction and industrial environments.
