Bootlace Ferrule Insulated 6mm2 Blue Clipsal
This insulated 6mm2 bootlace ferrule features a tinned copper barrel with a blue polypropylene sleeve for secure termination of fine-stranded conductors. Designed for electrical panels, control cabinets, switchboards, and automation systems, it supports applications up to 600V. Compliant with AS/NZS 3000 and AS/NZS 3820, it provides reliable wire termination with easy crimp installation. See the product details below for specifications, dimensions, and installation requirements.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable Ends Wire Ferrule | Tinned Copper | Blue Insulating Sleeve | 6mm² | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHDZ5CA063
Alternatively Known As: Wire Ferrule, Bootlace Ferrule, Cable End Sleeve, Wire End Terminal, Bootlace Terminal
Technical Specifications
- Type: Cable End Terminal (Wire Ferrule)
- Material: Tinned copper with insulating sleeve
- Wire Size: 6mm²
- Colour: Blue
- Length: 12mm
- Insulation: Polypropylene
- Operating Temperature: -40°C to +105°C
- Voltage Rating: 600V
- Dimensions (H x L x W): 2mm x 12mm x 2mm
- Weight: 0.1 kg
Key Features
- Provides secure and reliable wire termination
- Prevents wire strand fraying and breakage
- Improves electrical contact and connection integrity
- Suitable for stranded wire applications
- Easy to crimp and install
Professional Installation Requirements
- Installation should be performed by a qualified electrician using appropriate crimping tools to ensure secure and compliant connections.
Applications
- Electrical panel wiring
- Industrial control cabinets
- Switchboards
- Automation systems
- General electrical installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Reduces risk of electrical faults, minimizing waste and maintenance
- Enhances longevity of electrical connections, reducing replacement frequency
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal SCHDZ5CA063 Cable End Terminal is available for immediate purchase. Ideal for electrical panel wiring, control cabinets, and general electrical installations.
FAQ
Q: What conductor size is this bootlace ferrule suitable for?
A: It is designed for terminating 6mm2 fine-stranded conductors using appropriate crimping tools.
Q: Where can this bootlace ferrule be used?
A: It is suitable for electrical panel wiring, industrial control cabinets, switchboards, automation systems, and general electrical installations.
Pair this bootlace ferrule with a bootlace ferrule strip to improve efficiency when preparing multiple wire terminations.
Use a twin bootlace ferrule when connecting two stranded conductors into a single terminal.
Complete compatible wiring assemblies with an insulated pin connector for secure conductor terminations.
