Busbar MV Insulation Tubing 120/50mm | Up to 36kV | Adhesive Lined & Flame Retardant | Durable UV Resistance by Cabac
Cabac Busbar MV Insulation Tubing 120/50mm is a medium wall heatshrink tubing designed for up to 36kV applications, improving insulation and reducing busbar clearance distances with high tracking resistance and adhesive lining.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Busbar Mv Insulation Tubing 120/50mm
Brand: Cabac
SKU: BBMV120-50
Alternatively Known As: Medium Wall Heatshrink Tubing, MV Busbar Insulation Sleeve, High Voltage Heatshrink Tubing
Technical Specifications
- Medium wall heatshrink tubing suitable for up to 36kV
- Adhesive lined for improved sealing
- High tracking resistance
- Flame retardant and non-halogen based
- Durable against UV and solvents
- Mechanically strong
- Dimensions (H x L x W): 50mm x 1219mm x 120mm
- Weight: 0.2 kg
Key Features
- Adhesive lined for improved sealing
- High tracking resistance up to 36kV
- Flame retardant and non-halogen based material
- Extremely durable against UV exposure and solvents
- Mechanically strong for robust protection
Professional Installation Requirements
- Installation should be performed by a qualified electrician experienced with medium voltage electrical components to ensure safety and compliance.
Applications
- Electrical insulation for medium voltage busbars
- Improving insulation and reducing busbar clearance distances in electrical installations
- Suitable for rectangular or circular busbars in industrial and commercial electrical systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Non-halogen based material reduces environmental impact during disposal
- Flame retardant properties enhance safety and reduce fire hazards
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac Busbar MV Insulation Tubing 120/50mm is available for immediate purchase, ideal for medium voltage electrical insulation applications.
