Trade Discount 20%
Buss Aircraft Limiter ANL-600 | 600 Amp Rating | 6 kAIC Interrupt | Blade End Connection | @Each by Eaton
The Buss Aircraft Limiter ANL-600 is designed for high current circuit protection in aircraft and industrial electrical systems. With a robust 600 Ampere rating and an interrupt rating of 6 kAIC at 32 Vac, this non-indicating fuse ensures reliable performance. Ideal for automotive and marine applications, it features a compact design and blade end connections for easy installation by qualified technicians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Buss Aircraft Limiter ANL-600 | 600 Amp Rating | 6 kAIC Interrupt | Blade End Connection | @Each by Eaton
Brand: Eaton
SKU: ANL-600
Alternatively Known As: ANL-600 Fuse, Aircraft Circuit Limiter, Bussmann ANL Fuse, Eaton ANL-600 Fuse
Technical Specifications
- Amperage Rating: 600 A
- Interrupt Rating: 6 kAIC at 32 Vac, 2.7 kAIC at 80 Vdc
- Voltage Rating: 32 Vac, 80 Vdc
- Connection Type: Blade end x blade end
- Mounting Method: Stud
- Fuse Indicator: Non-indicating
- Dimensions (H x L x W): 41mm x 86mm x 24mm
- Weight: 0.14 kg
Key Features
- 600 Ampere current rating
- Interrupt rating of 6 kAIC at 32 Vac and 2.7 kAIC at 80 Vdc
- Blade end to blade end connection
- Stud mounting method
- Non-indicating fuse type
- Compact small footprint design
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician experienced with high current electrical systems to ensure safety and compliance.
Applications
- Aircraft electrical systems requiring high current circuit protection
- Industrial and commercial electrical panels
- Automotive and marine electrical systems with high current demands
Standards & Compliance
- AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- RoHS compliant, ensuring reduced hazardous substances in manufacturing
Warranty Information
No warranty applicable.
Available Now
The Eaton Bussmann ANL-600 Aircraft Circuit Limiter is available for immediate purchase, ideal for aircraft and industrial electrical protection applications.
