C60H-DC Circuit Breaker | 500V DC Rated | 10kA Breaking Capacity | Compact Design | @Pack of 1 | by Clipsal
The C60H-DC Circuit Breaker is designed for 500V DC applications, featuring a high breaking capacity of 10kA and a compact modular design for easy installation. Ideal for photovoltaic systems and DC power distribution, this breaker ensures reliable protection against overloads and short circuits, making it perfect for industrial control panels and battery storage systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: C60H-DC Circuit Breaker | 500V DC Rated | 10kA Breaking Capacity | Compact Design | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHMGN61534
Alternatively Known As: DC Miniature Circuit Breaker, DC MCB, Clipsal C60H-DC, 500VDC Breaker, SCHMGN61534
Technical Specifications
- Rated voltage: 500V DC
- Breaking capacity: 10kA
- Number of poles: 1P
- Tripping curve: C
- Thermal-magnetic trip unit
- Operating temperature: -25°C to +70°C
- Mounting: DIN rail
- Terminal capacity: 1-25mm²
- Dimensions (H x L x W): 85mm x 75mm x 18mm
- Weight: 0.15 kg
Key Features
- Rated for up to 500V DC applications
- High breaking capacity for reliable protection
- Compact modular design for easy installation
- Suitable for use in photovoltaic and DC circuits
- Thermal-magnetic trip unit for overload and short-circuit protection
Professional Installation Requirements
- Installation must be performed by a licensed electrician experienced with DC systems and photovoltaic installations.
Applications
- Photovoltaic (solar) installations
- DC power distribution panels
- Industrial control panels
- Battery storage systems
- Telecommunications equipment
Standards & Compliance
- Complies with AS/NZS 60947.2 for circuit breakers
- Complies with AS/NZS 5033 for photovoltaic installations
Environmental Benefits
- Enhances safety in renewable energy systems such as solar installations
- Supports efficient energy management and reduces risk of electrical fires
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal C60H-DC 500VDC Circuit Breaker (SCHMGN61534) is available for immediate purchase. Ideal for solar, battery, and industrial DC protection applications.
