Cable Gland Brass Hazardous Barrier IP66/68 M20 | 16-20mm Cable Diameter | Indoor/Outdoor Use | by Wattmaster
The Cable Gland Brass Hazardous Barrier IP66/68 M20 is designed for sealing armoured cables with a diameter of 16-20mm, making it ideal for hazardous area installations. With IP66/68 protection, it ensures reliable performance in both indoor and outdoor environments, effectively preventing dust and water ingress. Certified for Ex db I/IIC and Ex eb I/IIC areas, this durable brass construction enhances system longevity and safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable Gland Brass Hazardous Barrier IP66/68 M20 | 16-20mm Cable Diameter | Indoor/Outdoor Use | by Wattmaster
Brand: Wattmaster
SKU: ALCHAW25A-B
Alternatively Known As: Hazardous Area Cable Gland, Brass Barrier Cable Gland, Explosion Proof Cable Gland, Armoured Cable Gland M20
Technical Specifications
- Cable Diameter Range: 16-20mm
- Thread Size: M20
- Ingress Protection: IP66/68 (30m underwater)
- Standards: IEC/AS/NZS 60079 (.0, .1, .7, .31), IEC 60529, AS 1939-1990
- Certification: IEC Ex TSA 13.0001, ANZ Ex 13.3000
- Material: Brass
- Suitable for Ex db I/IIC, Ex eb I/IIC, Ex ta IIIC hazardous areas
- Locknut included
- Dimensions (H x L x W): 40mm x 50mm x 30mm
- Weight: 0.15 kg
Key Features
- Barrier kit suitable for indoor or outdoor use
- Seals cable sheath and clamps steel wire armour (SWA)
- Certified for Ex db I/IIC, Ex eb I/IIC, Ex ta IIIC hazardous areas
- IP66/68 rated for protection up to 30 meters underwater
- Includes barrier material and locknut as standard
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician trained in hazardous area equipment to ensure compliance with safety standards.
Applications
- Industrial hazardous area cable sealing
- Armoured cable installations requiring explosion protection
- Indoor and outdoor hazardous environments
Standards & Compliance
- AS/NZS 60079 – Explosive atmospheres standards compliance
Environmental Benefits
- Durable brass construction reduces need for frequent replacements
- Seals cables effectively to prevent ingress of dust and water, enhancing system longevity
Warranty Information
Standard manufacturer warranty applies; typically 12 months against manufacturing defects.
Available Now
The Wattmaster Brass Hazardous Barrier Cable Gland IP66/68 M20 for Armoured Cable 16-20mm is available for immediate purchase, ideal for hazardous area industrial and commercial electrical installations.
