Cable Gland Brass Hazardous Barrier IP66/68 M20 | 24-28mm Cable Diameter | Explosion Proof | by Wattmaster
The Cable Gland Brass Hazardous Barrier IP66/68 M20 is designed for armoured cables with a diameter of 24-28mm, providing robust protection in hazardous areas. Certified for Ex db I/IIC and Ex eb I/IIC applications, it ensures a secure seal against dust and water ingress, making it ideal for both indoor and outdoor electrical installations. Built from durable brass, this gland minimizes environmental contamination and supports safe electrical setups.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable Gland Brass Hazardous Barrier IP66/68 M20 | 24-28mm Cable Diameter | Explosion Proof | by Wattmaster
Brand: Wattmaster
SKU: ALCHAW32A-B
Alternatively Known As: Hazardous Area Cable Gland, Brass Barrier Cable Gland, IP68 Cable Gland, Explosion Proof Cable Gland
Technical Specifications
- Cable Diameter Range: 24-28mm
- Thread Size: M20
- Ingress Protection: IP66/68 (30m)
- Material: Brass
- Standards: IEC/AS/NZS 60079 (.0, .1, .7, .31), IEC 60529, AS 1939-1990
- Certification: IEC Ex TSA 13.0001, ANZ Ex 13.3000
- Suitable for Ex db I/IIC, Ex eb I/IIC, Ex ta IIIC hazardous areas
- Includes barrier material and locknut
- Dimensions (H x L x W): 50mm x 50mm x 30mm
- Weight: 0.15 kg
Key Features
- Barrier kit suitable for indoor or outdoor use
- Provides effective seal on cable sheath and clamps SWA
- Certified for Ex db I/IIC, Ex eb I/IIC, Ex ta IIIC hazardous areas
- IP66/68 rated for protection against dust and water ingress up to 30m
- Includes barrier material and locknut as standard
Professional Installation Requirements
- Installation must be performed by a qualified electrician experienced in hazardous area equipment to ensure compliance with safety standards.
Applications
- Industrial hazardous area cable sealing
- Armoured cable installations requiring explosion protection
- Indoor and outdoor electrical installations in hazardous zones
Standards & Compliance
- AS/NZS 60079 – Explosive atmospheres standards compliance
Environmental Benefits
- Durable brass construction reduces need for frequent replacements
- Seals cables effectively to prevent environmental contamination
- Supports safe electrical installations minimizing risk of hazardous leaks
Warranty Information
Standard manufacturer warranty applies; typically 1 year against manufacturing defects.
Available Now
The Wattmaster Brass Hazardous Barrier Cable Gland IP66/68 M20 for armoured cables 24-28mm is available for immediate purchase, ideal for hazardous area electrical installations requiring certified explosion protection.
