Cable Gland Brass Hazardous IP66/68 M40 | 32-37mm Diameter | Ex Rated | by Wattmaster
The Cable Gland Brass Hazardous IP66/68 M40 is designed for armoured cables with a diameter of 32-37mm, providing a secure seal and certified for hazardous locations. With high ingress protection rated IP66/68, it’s perfect for indoor and outdoor installations in explosive atmospheres, ensuring safety and compliance with industry standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable Gland Brass Hazardous IP66/68 M40 | 32-37mm Diameter | Ex Rated | by Wattmaster
Brand: Wattmaster
SKU: ALCHAW40A
Alternatively Known As: Brass Hazardous Cable Gland M40, Armoured Cable Gland IP66/68, Ex Rated Cable Gland 32-37mm
Technical Specifications
- Cable Diameter Range: 32-37mm
- Material: Brass
- Ingress Protection: IP66/68 (30m)
- Certification: IEC Ex TSA 13.0001, ANZ Ex 13.3000
- Standards: IEC/AS/NZS 60079 (.0, .1, .7, .31), IEC 60529, AS 1939-1990
- Ex Ratings: Ex db I/IIC, Ex eb I/IIC, Ex ta IIIC
- Locknut: Supplied as standard
- Dimensions (H x L x W): 40mm x 70mm x 40mm
- Weight: 0.3 kg
Key Features
- Suitable for armoured cables with diameter 32-37mm
- Provides a secure seal on cable sheath and clamps SWA
- Certified for hazardous locations with Ex db I/IIC, Ex eb I/IIC, Ex ta IIIC ratings
- High ingress protection rated IP66/68 (30m)
- Includes locknut as standard for secure fitting
Professional Installation Requirements
- Installation should be performed by a qualified professional familiar with hazardous area electrical installations to ensure compliance with safety standards.
Applications
- Indoor and outdoor hazardous area cable sealing
- Armoured cable installations requiring Ex protection
- Industrial environments with explosive atmospheres
Standards & Compliance
- AS/NZS 60079 – Explosive atmospheres standards compliance
Environmental Benefits
- Durable brass construction reduces need for frequent replacements
- High ingress protection prevents environmental contamination and cable damage
Warranty Information
Standard manufacturer warranty applies; please refer to Wattmaster for specific warranty terms.
Available Now
Available for immediate purchase, ideal for hazardous area armoured cable installations requiring high ingress protection and explosion-proof certification.
