Cable Gland Brass Weatherproof M16 | IP66/68 Rated | 1.5-6mm Cable Diameter | by Wattmaster
The Cable Gland Brass Weatherproof M16 is designed for unarmoured cables with a diameter of 1.5-6mm, providing exceptional protection against water ingress with an IP66/68 rating. Ideal for both indoor and outdoor electrical installations, this durable gland features brass construction with nickel plating for corrosion resistance and includes a locknut for secure installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable Gland Brass Weatherproof M16 | IP66/68 Rated | 1.5-6mm Cable Diameter | by Wattmaster
Brand: Wattmaster
SKU: ALCUW16S
Alternatively Known As: Brass Cable Gland M16, Weatherproof Cable Gland, Unarmoured Cable Gland, IP68 Cable Gland
Technical Specifications
- Cable Diameter Compatibility: 1.5-6.0 mm
- Material: Brass with nickel plating
- Seal Material: Thermoplastic Elastomer (TPE)
- Ingress Protection: IP66/68 (30m water depth)
- Temperature Range: –20°C to +80°C
- Locknut: Included
- Dimensions (H x L x W): 20mm x 40mm x 20mm
- Weight: 0.1 kg
Key Features
- Suitable for unarmoured cables with diameter 1.5-6mm
- Weatherproof design with IP66/68 rating (30m water ingress protection)
- Brass construction with nickel plating for corrosion resistance
- Includes locknut for secure installation
- Seal made from TPE for effective cable sheath sealing
- Temperature range from –20°C to +80°C
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper sealing and compliance with electrical safety standards.
Applications
- Indoor and outdoor cable sealing
- Electrical installations requiring weatherproof cable glands
- Industrial and commercial wiring protection
Standards & Compliance
- Complies with AS 1939-1990 for cable glands
Environmental Benefits
- Durable brass and nickel plating extend product life, reducing waste
- Weatherproof sealing prevents environmental damage to cables, enhancing system longevity
Warranty Information
Standard manufacturer warranty applies; typically 1 year against manufacturing defects.
Available Now
The Wattmaster Brass Weatherproof Cable Gland M16 is available for immediate purchase, ideal for protecting unarmoured cables in both indoor and outdoor electrical installations.
