Cable Gland Weatherproof Armoured Cable | IP66/68 Rated | Brass Construction | 6-12mm Diameter | by Wattmaster
The Cable Gland Weatherproof Armoured Cable is designed for secure sealing of armoured cables with a diameter range of 6-12mm. Featuring a robust IP66/68 protection rating and durable brass construction, it’s perfect for both indoor and outdoor electrical installations. Ideal for industrial, commercial, and residential applications, this gland ensures reliable performance in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable Gland Weatherproof Armoured Cable | IP66/68 Rated | Brass Construction | 6-12mm Diameter | by Wattmaster
Brand: Wattmaster
SKU: ALCAW20Z
Alternatively Known As: Armoured Cable Gland, Weatherproof Cable Gland, Brass Cable Gland, IP68 Cable Gland
Technical Specifications
- Cable Diameter Range: 6-12mm
- Thread Length: 12mm
- Material: Brass, Nickel Plated
- Seal Material: TPE
- Ingress Protection: IP66/68
- Temperature Range: –20°C to +80°C
- Locknut: Supplied as standard
- Compliance: AS 1939-1990
- Dimensions (H x L x W): 20mm x 30mm x 20mm
- Weight: 0.1 kg
Key Features
- Weatherproof design with IP66/68 protection rating
- Suitable for armoured cables with diameter 6-12mm
- Temperature range from –20°C to +80°C
- Brass construction with nickel plating for durability
- Includes locknut and TPE seal for secure cable sealing
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper sealing and compliance with electrical standards.
Applications
- Suitable for indoor and outdoor use
- Ideal for sealing armoured cables in electrical installations
- Used in industrial, commercial, and residential electrical wiring
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable brass and nickel plating extend product life, reducing waste
- Weatherproof sealing prevents ingress of water, protecting electrical systems and reducing maintenance
Warranty Information
Standard manufacturer warranty applies. Please refer to Wattmaster warranty policy for details.
Available Now
Available for immediate purchase, ideal for securing and weatherproofing armoured cables in various electrical installations.
