Cable Security Figure 8 24/0.20 | Plain Annealed Copper | PVC Insulation | 100V DC Rating | by Electra Cables
Cable Security Figure 8 24/0.20 is designed for reliable security system installations, featuring a plain annealed copper conductor and durable PVC insulation. With a voltage rating of 100V DC or 32V AC, this cable is perfect for access control and communications equipment, ensuring optimal performance and longevity in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Figure 8 Security Cable, Security Control Cable, Access Control Cable
Technical Specifications
- Conductor: Plain annealed copper
- Insulation: PVC V75
- Sheath: PVC V75
- Voltage rating: 100V DC or 32V AC
- Standard compliance: AS/NZS 1125 (Conductor), AS/NZS 3808 (PVC)
- Dimensions (H x L x W): 6mm x 100000mm x 6mm
- Weight: 1.2 kg
Key Features
- Plain annealed copper conductor for reliable conductivity
- PVC V75 insulation and sheath for durability and protection
- Voltage rating of 100V DC or 32V AC
Professional Installation Requirements
- Installation should be performed by a qualified technician to ensure compliance with safety and operational standards.
Applications
- Security systems
- Control and communications equipment
- Access control
- Detection and monitoring
Standards & Compliance
- AS/NZS 1125 – Conductor standards
- AS/NZS 3808 – PVC insulation and sheath standards
Environmental Benefits
- PVC insulation and sheath are recyclable materials
- Durable construction reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty applies. Please refer to Electra Cables for detailed warranty terms.
Available Now
Electra Cables Cable Security Figure 8 24/0.20 100M Clear is available for immediate purchase, ideal for security and control system installations.
