Cable XLPE 120mm 4 Core+Earth | UV Stabilised Orange Sheath | 0.6/1kV Voltage Rating | @Pack of 0.10 | by Electra Cables
The Cable XLPE 120mm 4 Core+Earth is designed for robust power distribution, featuring a UV stabilised orange sheath and XLPE insulation for superior electrical performance. Ideal for commercial and industrial applications, this cable ensures safety with its 4 core plus earth configuration and is perfect for underground and mains power supply installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable XLPE 120mm 4 Core+Earth | UV Stabilised Orange Sheath | 0.6/1kV Voltage Rating | @Pack of 0.10 | by Electra Cables
Brand: Electra Cables
SKU: XLPE41200+E-BOR
Alternatively Known As: 120mm XLPE 4 Core + Earth Cable, 4C+E 120mm Power Cable, XLPE Mains Cable, Heavy Duty Orange Power Cable, Underground Power Cable
Technical Specifications
- Conductor: Stranded copper
- Insulation: Cross-linked polyethylene (XLPE)
- Sheath: UV stabilised orange PVC, LSZH
- Core size: 120mm²
- Configuration: 4 core + earth
- Voltage rating: 0.6/1kV
- Length: 100 metres
- Operating temperature: -15°C to +90°C
- Complies with AS/NZS 5000.1
- Dimensions (H x L x W): 70mm x 100000mm x 70mm
- Weight: 420 kg
Key Features
- XLPE insulated for superior electrical and thermal performance
- 4 core plus earth configuration for enhanced safety
- UV stabilised orange sheath for outdoor and underground use
- Low smoke, zero halogen (LSZH) properties
- High current carrying capacity
- 100 metre continuous length for large installations
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial power distribution
- Underground and mains power supply
- Construction sites and infrastructure projects
- Suitable for fixed wiring in buildings and switchboards
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 5000.1 – Electric cables with extruded insulation and low voltage
Environmental Benefits
- Low smoke zero halogen (LSZH) sheath reduces toxic emissions in case of fire
- UV stabilised for long outdoor service life
- Durable construction reduces need for frequent replacement
Warranty Information
12 months manufacturer's warranty against defects in materials and workmanship.
Available Now
Available for immediate purchase. Ideal for commercial, industrial, and infrastructure electrical installations requiring high-capacity, durable power cabling.
